    Thick Gold PCB Prototype Multilayers Rohs 94v0 High Complexity Immersion Gold Surface

    Thick gold PCB Prototype multilayers PCB Rohs 94v0 high complexity PCB


    Advantages


    - No MOQ

    - OEM services provided

    - Heavy copper PCB, Heavy gold PCB, Blind / Buried via PCB, High layer count PCB manufacturable

    - Factory direct price

    - Replying with price in one working day

    - Shipping within 24 hours

    - Certificate: ROHS, UL, ISO9001-2000, ISO14001,SGS Lead-Free


    PCB General Capability

    Number of Layer

    1 - 18 Layer

    Maximum Processing Area

    680 × 1000MM

    Min Board Thickness

    2 Layer - 0.3MM ( 12 mil )

    4 Layer - 0.4MM ( 16 mil )

    6 Layer - 0.8MM ( 32 mil )

    8 Layer - 1.0MM ( 40 mil)

    10 Layer - 1.1MM ( 44 mil )

    12 Layer - 1.3MM ( 52 mil )

    14 Layer - 1.5MM ( 59 mil )

    16 Layer - 1.6MM ( 63 mil )

    18 Layer - 1.8MM ( 71 mil )

    Finished Board Thickness Tolerance

    Thickness ≤ 1.0MM, Tolerance: ± 0.1MM

    1.0MM ≤ Thickness ≤ 6.5MM, Tolerance ± 10%

    Twisting and Bending

    ≤ 0.75%, Min: 0.5%

    Range of TG

    130 - 215 ℃

    Impedance Tolerance

    ± 10%, Min: ± 5%

    Hi-Pot Test

    Max: 4000V/10MA/60S

    Surface Treatment

    HASL, With Lead, HASL Free Lead

    Flash Gold, Immersion Gold

    Immersion Silver, Immersion Tin

    Gold Finger, OSP


    PCB Capacity


    Item
    Capability---Technology
    Standard
    IPC-A-610 E Class II-III
    Laminate/Base Material
    FR-4 / PI (FPC) / High TG FR-4 / Halogen Free material/Rogers/Arlon/
    Taconic/Teflon/CEM-3/PTFE/Aluminum /BT
    Layers
    1-18
    Finised inner/outer copper thickness
    1-6 OZ
    Board Thinkness
    0.2-5.0mm
    Min hole size
    Mechanical hole: 0.15mm
    Laser hole: 0.1mm
    Min line width/space
    0.075mm/0.075mm
    Min line Gap
    +/-10%
    Aspect Ratio
    12:1
    Controlled Impedance
    <= +/-10%
    Solder Mask Color
    Green,Blue,Black,White,Yellow,Red,Grey,Purple etc..
    Outline profile
    Rout/ V-cut/ Bridge/ Stamp hole
    Surface treatment
    HASL, HASL lead free, Immersion Gold,ENEPIG, Immersion Tin, Immersion Silver, Hard gold, Flash gold, OSP...
    Tolerance of dimension size
    +/-0.1mm
    Capacity
    35000sq/Month
    CAM Capability
    40 item
